Program Features:
- Parallel computing using OPENMP in MatLab.
- Support empirical constitutive model such as: Mander [1], Attard and Setunge [2], and Samani and Attard [3].
Future Development:
- The code will be complete migrated to VC#.Net and the heteregenous computing is employed to massively speed up the computation.
- Inter-connecting with ITS-RCCAD program will be deployed in the future using Windows Communication Foundation (WCF). Hence, 3D-NLFRAME will only focus on the development of the upper scale (Frame Analysis)
while ITS-RCCAD focus on the lower scale (Sectional Analysis).
- Samani and Attard [4] concrete Lateral strain model will be added to nullified the requirement to compute the effective confinement presure when the ties is yielding.
References:
[1] 1988, Mander JB, Priestley MJN, Park R, "Theoretical stress-strain model for confined concrete.", ASCE Journal of Structural Engineering, 114 (8).
[2] 1996, Attard MM, Setunge, "Stress-strain relationship of confined and unconfined concrete." ACI Materials Journal 93 (5), 432-442.
[3] 2012, Samani AK, Attard MM, "A stress strain model for uniaxial and confined concrete under compression." Elsevier - Engineering Structures, 41, 335-349.
[4] 2014, Samani AK, Attard MM, "Lateral strain model for concrete under compression." ACI Structurals Journal 111 (2), 441-451.
